Dinky™ (DK)
The Charvel USA Select DK24 HSS 2PT CM QM is an exquisite USA-made instrument designed for modern players with discerning tastes. Born on west coast soil, the USA DK24 is meticulously built by the Charvel team at the Custom Shop in Corona, California, so nothing about this high-performance axe is overlooked.
-
Overview
The Dinky® alder body features a rippling quilt maple top and is paired with a bolt-on caramelized maple "speed" neck with graphite reinforcement, sculpted heel and a silky-smooth hand-rubbed urethane back finish for comfortable playability. The back of the body features a scalloped lower back bout that works in tandem with the shredder's cut heel to allow for easy upper fretboard access.
Built for highly-technical playing, its 12"-16" compound radius caramelized maple fingerboard features comfortable rolled edges, 24 stainless steel jumbo frets, pearl dot inlays and a Graph Tech® TUSQ® XL nut. Luminlay® side dots provide fretboard guidance even on the darkest of stages, while a heel-mount truss rod adjustment wheel makes for quick and painless neck relief tweaks.
An HSS pickup configuration consisting of a custom Seymour Duncan® Full Shred™ TB-10 bridge pickup, Seymour Duncan Custom Flat Strat® SSL-6 single-coil middle pickup and Seymour Duncan Custom Flat Strat SSL-6 RWRP single-coil neck pickup proves to be a versatile tonal force with beefed up mids and articulated, crispy highs.
Other premium modern features include a five-way blade switch, Stratocaster®-style skirt knobs for the volume (with 500K EVH® Bourns® low friction potentiometer) and no-load tone controls, Gotoh® Custom 510 recessed tremolo bridge with titanium saddles and thick brass block, USA-made Sperzel® locking tuners, and more.
Sporting sophisticated style, sound and craftmanship, the USA Select DK24 HSS 2PT CM QM is available in Autumn Glow or Blue Burst with masked-off natural binding chrome hardware.
-
Features
Alder Body with Quilt Maple Top
12"-16" Compound Radius Caramelized Maple Fingerboard
Scalloped Lower Back Bout
Beveled Output Jack
Shredder's Cut Heel
Sperzel® Die-Cast Tuning Machines
Seymour Duncan® Custom Full Shred™ SH-10B bridge, Seymour Duncan® Custom Flat Strat® SSL-6 Single-Coil middle & Seymour Duncan® Custom Flat Strat® SSL-6 RWRP Single-Coil neck pickups
Luminlay® Side Dots
Heel-Mount Truss Rod Adjustment Wheel
Gotoh® Custom 510 Recessed Tremolo Bridge with Titanium Saddles and Thick Brass Block -
Specs
General
Model Number 2839413799 Series USA Select Color Blue Burst Number of Strings 6 Orientation Right-Hand Electronics
Bridge Pickup Seymour Duncan® Full Shred™ TB-10 Middle Pickup Seymour Duncan® Custom Flat Strat® SSL-6 Single-Coil Neck Pickup Seymour Duncan® Custom Flat Strat® SSL-6 RWRP Single-Coil Pickup Color Flat Black Controls Volume (with 500K EVH® Bourns® Low Friction Potentiometer), No-Load Tone Pickup Switching 5-Position Blade: Position 1. Bridge Pickup, Position 2. Inner Coil of Bridge and Middle Pickup, Position 3. Neck and Bridge Outer Coil, Position 4. Neck and Middle Pickup, Position 5. Neck Pickup Pickup Configuration HSS Body
Body Finish Gloss Body Shape Dinky® Body Material Alder Body Binding Masked-Off Natural Body Top Quilt Maple Hardware
Bridge Gotoh® Custom 510 Tremolo Bridge with Brass Block and Titanium Saddles Hardware Finish Chrome Tremolo Arm Gotoh® Tuning Machines Sperzel® Die-Cast Locking Pickguard None Control Knobs Stratocaster®-Style Skirt Switch Tip Black Neck
Neck Material Caramelized Flame Maple Neck Construction Bolt-On with Graphite Reinforcement Neck Finish Hand-Rubbed Urethane Neck Shape Speed Neck with Rolled Fingerboard Edges Neck Binding None - Rolled Fingerboard Edges Scale Length 25.5" (64.77 cm) Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm) Fingerboard Material Caramelized Flame Maple Number of Frets 24 Fret Size Jumbo Stainless Steel Nut Material Graph Tech TUSQ XL Nut Width 1.6875" (42.86 mm) Position Inlays 4mm Pearloid Dot Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel Headstock Licensed Fender® Stratocaster® Neck Plate 4-Bolt Sculpted Heel Miscellaneous
Strings Nickel Plated Steel (.009-.042 Gauges) Strap Buttons Standard Case/Gig Bag Included Charvel® Hardshell (p/n 009-0228-000); Optional Gig Bag (p/n 299-1414-006) -
Pickup Switching
-
