Dinky™ (DK)
Charvel® continues to up the ante for modern high performance combined with standout style and full-spectrum tone with the Pro-Mod DK22 SSS 2PT CM, a sleek new instrument designed especially for a new breed of player whose musical vision and versatility knows no boundaries.
-
Overview
Featuring a sculpted shredder's cut heel and scalloped lower back bout for comfortable and unencumbered upper fret access, the Dinky® alder body is paired with a graphite-reinforced bolt-on caramelized maple neck for rock-solid stability. The baked neck has a silky-smooth hand-rubbed satin urethane finish on the back for sublime playability, Luminlay® side dots to guide your way along the fretboard on dark stages and a heel-mount truss rod adjustment wheel for quick and painless neck relief tweaks. Designed for high-speed playing, its 12"-16" compound radius caramelized maple fingerboard features comfortable rolled edges, 22 jumbo frets, pearloid dot inlays and Graph Tech® TUSQ® XL nut.
Routed for an SSS pickup configuration, this axe combines a Seymour Duncan® Custom Hot Rails® Strat® SHR-1B humbucking bridge pickup, Seymour Duncan Custom Flat Strat SSL-6 single-coil middle pickup and Seymour Duncan Custom Flat Strat SSL-6 RWRP single-coil neck pickup for plenty of glassy, vintage-style timbre with classic Strat chime.
The Pro-Mod DK22 SSS 2PT CM hosts other premium modern features including a five-way blade pickup switch, Stratocaster®-style skirt knobs for the volume (500K EVH® Bourns® low friction potentiometer) and no-load tone controls, Gotoh® Custom 510 tremolo bridge, die-cast tuners and more.
Designed with head-turning style, the all-new DK22 SSS 2PT CM is available in Electric Blue, Gloss Black and Pharaohs Gold with chrome hardware. The Gloss Black model features matte black pickup bobbins and black control knobs, while the Electric Blue and Pharaohs Gold models feature matte parchment pickup bobbins and parchment knobs.
-
Features
Alder Dinky™ Body
12"-16" Compound Radius Caramelized Maple Fingerboard
Scalloped Lower Back Bout
Shredder's Cut Heel
Seymour Duncan® Custom Hot Rails® Strat® SHR-1B humbucking bridge, Seymour Duncan Custom Flat Strat® SSL-6 single-coil middle and Seymour Duncan Custom Flat Strat SSL-6 RWRP single-coil neck pickups
5-Way Blade, Volume Control with 500K EVH Bourns® Low Friction Potentiometer & No-Load Tone Control
Luminlay® Side Dots
Heel-Mount Truss Rod Adjustment Wheel
Gotoh® Custom 510 Tremolo
Graph Tech® TUSQ XL Nut -
Specs
General
Model Number 2969026503 Series Pro-Mod Color Gloss Black Number of Strings 6 Orientation Right-Hand Electronics
Bridge Pickup Seymour Duncan® Custom Hot Rails® Strat® SHR-1B Middle Pickup Custom Seymour Duncan® Flat Strat® SSL-6 Single-Coil Neck Pickup Custom Seymour Duncan® Flat Strat® SSL-6 RWRP Single-Coil Pickup Color Flat Black Controls Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone Pickup Switching 5-Position Blade: Position 1. Full Bridge Pickup, Position 2. Bridge Inner Coil and Middle Pickup, Position 3. Bridge Outer Coil and Neck Pickup, Position 4. Middle and Neck Pickup, Position 5. Full Neck Pickup Pickup Configuration SSS Hardware
Bridge Gotoh® Custom 510 Tremolo Hardware Finish Chrome Tremolo Arm Gotoh® Tuning Machines Charvel®-Branded Die-Cast Locking Pickguard None Control Knobs Stratocaster®-Style Skirt Switch Tip Black Saddle Height Wrench Yes Neck
Neck Material Caramelized Maple Neck Construction Bolt-On with Graphite Reinforcement Neck Finish Hand-Rubbed Satin Urethane Neck Shape Speed Neck with Rolled Fingerboard Edges Neck Binding None - Rolled Fingerboard Edges Scale Length 25.5" (64.77 cm) Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm) Fingerboard Material Caramelized Maple Number of Frets 22 Fret Size Jumbo Nut Material Graph Tech TUSQ XL Nut Width 1.6875" (42.86 mm) Position Inlays 4mm Pearloid Dot Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel String Trees Fender® Standard String Guide Headstock Licensed Fender® Stratocaster® Neck Plate None - 4-Bolt Sculpted Heel Miscellaneous
Strings Nickel Plated Steel (.009-.042 Gauges) Strap Buttons Standard Case/Gig Bag Optional Charvel® Hardshell (p/n 009-0915-000); Optional Gig Bag (p/n 007-6756-000) Other Features Luminlay® Side Dots -
Pickup Switching
-
Gallery
