San Dimas Style 1

Pro-Mod San Dimas® Style 1 HH HT Ash
2965071582 / Natural
Pro-Mod San Dimas® Style 1 HH HT Ash
2965071582 / Natural

Hot-rodded for breakneck performance, versatile sound and exquisite style, the Pro-Mod Series is packed with innovative design elements that have long made Charvel a legendary name in high-performance guitars. Continuing upon our storied legacy, the Pro-Mod San Dimas® Style 1 HH HT E Ash is tricked-out to meet the needs and exceed the expectations of today’s modern guitarist.

$799.99
  • Overview

    This high-octane instrument offers an ash body and bolt-on maple neck with a pair of graphite reinforcement rods to resist bending and warping under environmental stresses. The speed neck profile and 12”-16” compound radius aged ebony fingerboard are designed for warp speed playing, unhindered positional shifts and mile-wide upper register bends without fretting out, while the heel-mount truss rod wheel allows for quick and convenient neck relief adjustments.

    Designed to inspire, this instrument sports two high-output Seymour Duncan® humbucking pickups—a crisp, clear JB bridge pickup and a rich, fat ’59 neck pickup for robust tone with highly dynamic articulation and harmonic balance. The volume control conceals a push/pull coil split to have even more tonal variations on tap while the no-load tone control operates like a standard tone control from positions one through nine, removing itself from the circuit at position ten for transparent sound, letting the full natural voice of the guitar shine through. Play with confidence in the guitar’s tuning stability and intonation, thanks to the secure six-saddle hardtail bridge.

    As curvaceous as a high-performance hot rod, Charvel’s San Dimas guitars are widely acclaimed for their sleek style. A gold hardware package, including a Charvel neck plate, sealed die-cast locking tuners and dual vintage-style flat string trees are paired to this Natural finish for an understated and sophisticated look.

  • Features
    Ash Body
    Bolt-on Maple Neck with Graphite Reinforcement
    12"-16" Compound Radius
    Direct Mount Seymour Duncan JB TB-4/'59 SH-1N Pickups
    Unique Charvel Back Neckshape
    3-Way Blade, Push/Pull Volume & No-Load Tone Controls
    Heel-Mount Truss Rod Adjustment Wheel
    Charvel HT6 String-Through-Body Hardtail Bridge
    Ebony Fingerboard
  • Specs
    General
    Model Number 2965071582
    Est. U.S. Street $799.99
    Series Pro-Mod
    Color Natural
    Number of Strings 6
    Orientation Right-Hand
    Electronics
    Bridge Pickup Seymour Duncan® JB TB-4
    Neck Pickup Seymour Duncan® '59™ SH-1N
    Controls Volume (Push/Pull Coil Split), No-Load Tone
    Pickup Switching 3-Position Blade: Position 1. Bridge Pickup, Position 2. Both Inner Coils, Position 3. Neck Pickup - (Split Engaged) - Position 1. Bridge Outer Coil, Position 2. Both Outer Coils, Position 3. Neck Outer Coil
    Pickup Configuration HH
    Body
    Body Finish Satin
    Body Shape San Dimas® Style 1
    Body Material Ash
    Hardware
    Bridge Charvel® HT6 String-Through-Body Hardtail
    Hardware Finish Gold
    Tuning Machines Charvel®-Branded Die-Cast Locking
    Pickguard None
    Pickup Covers Parchment
    Control Knobs Knurled Flat-Top
    Switch Tip Black
    Neck
    Neck Material Maple
    Neck Construction Bolt-On
    Neck Finish Hand-Rubbed Satin Urethane
    Neck Shape Speed Neck with Rolled Fingerboard Edges
    Neck Binding None - Rolled Fingerboard Edges
    Scale Length 25.5" (648 mm)
    Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm)
    Fingerboard Material Aged Ebony
    Number of Frets 22
    Fret Size Jumbo
    Nut Width 1.6875" (42.86 mm)
    Position Inlays White Dot
    Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel
    Headstock Licensed Fender® Stratocaster®
    Neck Plate 4-Bolt Serialized
    Miscellaneous
    Strings Nickel Plated Steel (.009-.042 Gauges)
